Metal Gantry Shear

Input Size : Customize

Output Capacity : 200-10000kg/h

Applicable Material : thin steel material, steel bar, steel plate, nickel plate, steel plate, round steel, steel pipe, scrap copper, scrap iron, etc.





Product Description

Gantry scrap metal shears is used in steel plants, recycling companies, automobile dismantling plants, smelting & casting industry for cold-cutting all kinds of metal scrap (section steel, round steel, square steel, scrap car, metallic structural parts etc. ) into acceptable furnace charges. Gantry shear machine is especially designed for heavy metal scraps (common metal, structure steel, round steel, rebar) / HMS scrap / automobile scrap car etc. It adopts hydraulic drive, simple operation & easy maintenance..




Applicable materials:

Gantry shearing machine is a kind of equipment suitable for heavy scrap cutting processing, used for thin steel material, steel bar, steel plate, nickel plate, steel plate, round steel, steel pipe, scrap copper, scrap iron, light metal structural parts, stainless steel, metal pressing block, automobile body, aluminum alloy, copper, iron filings, steel wire, metal pressing block and other scrap metal cold cutting short, processing into qualified charge.

Advantages

Gantry hydraulic shear machine is compact in structure, and its body is made of steel plate welded into a box structure, with stable mechanical properties. The shear cylinder is connected by ball joint, which improves the stability and service life of the cylinder, adding the front plate guide device, and improves the stress condition of the whole machine. It is one of the ideal equipment in metal recovery industry and casting workshop for charge processing.

● Gantry shearing machine adopts hydraulic transmission, compared with mechanical transmission shearing machine, with small volume, light weight, small inertia, low noise, smooth action, easy to operate, flexible, large shear section, scissors mouth adjustment and other advantages, safe operation and use, easy to achieve overload protection.

● Gantry shearing machine has manual, automatic, remote control function, convenient and simple operation control, scissors mouth in the working process of any position to start cutting and stop, and can be cut according to the size of the material, arbitrary control of the size of the cutting mouth, in order to obtain economic benefits.

● Gantry shear designed fast type, without increasing the motor power and oil pump displacement condition, in (about 4001600 tons) shear speed to maintain fast, shear large material will automatically convert speed. The original shear force is restored and the working efficiency is nearly doubled.

● Gantry shear machine with fast device. Without increasing the motor power and oil pump displacement, a fast loop is designed to increase the cutting speed from 8 times per minute to 12 times per minute (refers to The Times when the scissors open), and improve the efficiency of nearly double. This function is unique in the national peer.

TECHNICAL PARAMETER

Model Shear force(tons) Processing capacity(t/h) Length of knife edge(mm) Shear frequency(次/分/sub) Power(kw)
LMJ-315 315 3-5 1200 2-4 22*2
LMJ-400 400 4-7 1400 2-4 37*2
LMJ-500 500 5-8 1500 2-4 45*2
LMJ-630 630 8-10 1600 2-4 45*3
LMJ-800 800 12-15 1800 2-4 55*3
LMJ-1000 1000 15-20 2000 2-4 55*4
LMJ-1250 1250 20-30 2500 2-4 55*4
